Status: all CUDA-capable devices are busy or unavailable

Ray Tune
#1

I verified that my models are defined inside the Trainable (as suggested here) but still see this error when I run it from tune.run.

I’m using ray 1.8, TF 2.4 and CUDA 11.1


exp_path = Path("./").resolve()
train_files, test_files = transform_data(raw_csv_files) # processes the data as a pandas dfs without

class MyModel(Trainable):
    def _dense_model(self):
        self.model_dir = Path(self.logdir)/"est_model_dir"
        dnn_est = tf.estimator.DNNClassifier(
            ...
            optimizer=lambda: tf.keras.optimizers.Adam(
                learning_rate=self.config["lr"]
            )
        )
        logging.warning("Saving model data to %s" % self.model_dir)
        return dnn_est

    def get_data(self):
        input_fn = partial(
            tf.compat.v1.data.experimental.make_csv_dataset,
            batch_size=self.config["batch_size"],
        ...)
        self.train_input_fn = lambda: input_fn(
            file_pattern=train_files)
        self.test_input_fn = lambda: input_fn(
            file_pattern=test_files)

    def setup(self, ray_config):
        # Ray sets current directory to trials directory for every trial.
        # Ray dev suggested this change https://groups.google.com/d/msg/ray-dev/T5q7DkkGlpQ/ZzbOTIsVBwAJ
        os.chdir(exp_path)  # to make sure all files saved by me are relative to this path
        self.model = self._dense_model()
        self.get_data()

    def step(self):
        self.model.train(self.train_input_fn, steps=self.config["epochs"] * self.config["steps_per_epoch"])
        val_metrics = self.model.evaluate(self.test_input_fn, steps=self.config["steps_per_epoch"], name="val")
        train_metrics = ...
        return {**train_metrics, **val_metrics}

    def save_checkpoint(self, checkpoint_dir):
        return self.export_model(["py"]) # so I have the final model after all training

    def _export_model(self, export_formats, export_dir):
        return self.model.save(export_dir)

The below outside, tune.run runs on GPUs perfectly.

t = MyModel({
    ... # some config
})

t.train()

But tiggering it this way, fails with Status: all CUDA-capable devices are busy or unavailable

tune.run(
    MyModel,
    name=exp_name,
    local_dir="./ray_results/",
    resources_per_trial={'gpu': 1},
    config={
        ...
    },
    stop={"training_iteration": ...},
    max_failures=0,
    num_samples=...,
    checkpoint_at_end=True, # so the final model is exported
    callbacks=[
        MLflowLoggerCallback(
            experiment_name=exp_name,
            save_artifact=True
        )
    ],
)
  1. What am I missing in the way I’m using Trainable?
  2. How do I systematically detect any leaks (i.e. TF code written outside Trainable)?

Thank you, for helping me :slight_smile:

CUDA error: all CUDA-capable devices are busy or unavailable
ERROR gcs_utils.py:137 -- Failed to send request to gcs
#2

Nice!

Maybe try using Training (tune.Trainable, tune.report) — Ray v1.10.0 ?

#3

Thanks for taking a look, @rliaw

  1. Why is a conditional wait_for_gpu not part of Trainable.train() by default? What was your intuition behind this? I see this behavior immediately and not during the experiment.
  2. Do you see any leaks with my usage of Trainable?
#4

Can you try and see if it works if you remove the conditional?

Unfortunately I didn’t have much time to run the code exactly.

#5

So concretely, can you report back your results after you try doing tune.util.wait_for_gpu() in def step()?

Also, perhaps you could consider explicitly setting tune.run(reuse_actors=False)

1 Like
#6
== Status ==
Current time: 2022-02-13 06:07:29 (running for 00:00:50.97)
Memory usage on this node: 19.9/xxx GiB
Using FIFO scheduling algorithm.
Resources requested: 1.0/8 CPUs, 1.0/2 GPUs, 0.0/43.38 GiB heap, 0.0/9.31 GiB objects (0.0/1.0 accelerator_type:V100)
Result logdir: /home/jovyan/...
Number of trials: 1/1 (1 RUNNING)

(pid=550) 2022-02-13 06:07:32,236	INFO util.py:462 -- Waiting for GPU util to reach 0.01. Util: 0.014

It failed after some time. So I changed my step() fn to tune.utils.wait_for_gpu(target_util=0.02). It continued but it failed due to the same error I opened this topic with.

(pid=347) 2022-02-13 06:21:54.914399: I tensorflow/compiler/jit/xla_cpu_device.cc:41] Not creating XLA devices, tf_xla_enable_xla_devices not set
(pid=347) 2022-02-13 06:21:54.915827: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcuda.so.1
(pid=347) 2022-02-13 06:21:54.933441: I tensorflow/core/common_runtime/gpu/gpu_device.cc:1720] Found device 0 with properties:
(pid=347) pciBusID: 0000:da:00.0 name: Tesla V100-PCIE-32GB computeCapability: 7.0
(pid=347) coreClock: 1.38GHz coreCount: 80 deviceMemorySize: 31.75GiB deviceMemoryBandwidth: 836.37GiB/s
(pid=347) 2022-02-13 06:21:54.933483: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcudart.so.11.0
(pid=347) 2022-02-13 06:21:54.937109: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcublas.so.11
(pid=347) 2022-02-13 06:21:54.937187: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcublasLt.so.11
(pid=347) 2022-02-13 06:21:54.938507: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcufft.so.10
(pid=347) 2022-02-13 06:21:54.938785: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcurand.so.10
(pid=347) 2022-02-13 06:21:54.942326: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcusolver.so.10
(pid=347) 2022-02-13 06:21:54.943053: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcusparse.so.11
(pid=347) 2022-02-13 06:21:54.943262: I tensorflow/stream_executor/platform/default/dso_loader.cc:49] Successfully opened dynamic library libcudnn.so.8
(pid=347) 2022-02-13 06:21:54.945908: I tensorflow/core/common_runtime/gpu/gpu_device.cc:1862] Adding visible gpu devices: 0
2022-02-13 06:21:57,117	ERROR trial_runner.py:924 -- Trial MyModel_3b81c_00000: Error processing event.
Traceback (most recent call last):
  File "/home/jovyan/.local/lib/python3.7/site-packages/ray/tune/trial_runner.py", line 890, in _process_trial
    results = self.trial_executor.fetch_result(trial)
  File "/home/jovyan/.local/lib/python3.7/site-packages/ray/tune/ray_trial_executor.py", line 788, in fetch_result
    result = ray.get(trial_future[0], timeout=DEFAULT_GET_TIMEOUT)
  File "/home/jovyan/.local/lib/python3.7/site-packages/ray/_private/client_mode_hook.py", line 105, in wrapper
    return func(*args, **kwargs)
  File "/home/jovyan/.local/lib/python3.7/site-packages/ray/worker.py", line 1625, in get
    raise value.as_instanceof_cause()
ray.exceptions.RayTaskError(InternalError): ray::MyModel.train() (pid=347, ip=100.96.202.248, repr=<__main__.MyModel object at 0x7f229838e690>)
  File "/home/jovyan/.local/lib/python3.7/site-packages/ray/tune/trainable.py", line 283, in train
    result = self.step()
  File "<ipython-input-26-cc6f45585ccc>", line 92, in step
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow_estimator/python/estimator/estimator.py", line 349, in train
    loss = self._train_model(input_fn, hooks, saving_listeners)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow_estimator/python/estimator/estimator.py", line 1175, in _train_model
    return self._train_model_default(input_fn, hooks, saving_listeners)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow_estimator/python/estimator/estimator.py", line 1208, in _train_model_default
    saving_listeners)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow_estimator/python/estimator/estimator.py", line 1510, in _train_with_estimator_spec
    save_graph_def=self._config.checkpoint_save_graph_def) as mon_sess:
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 604, in MonitoredTrainingSession
    stop_grace_period_secs=stop_grace_period_secs)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 1038, in __init__
    stop_grace_period_secs=stop_grace_period_secs)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 749, in __init__
    self._sess = _RecoverableSession(self._coordinated_creator)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 1231, in __init__
    _WrappedSession.__init__(self, self._create_session())
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 1236, in _create_session
    return self._sess_creator.create_session()
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 902, in create_session
    self.tf_sess = self._session_creator.create_session()
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/monitored_session.py", line 669, in create_session
    init_fn=self._scaffold.init_fn)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/session_manager.py", line 295, in prepare_session
    config=config)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/training/session_manager.py", line 199, in _restore_checkpoint
    sess = session.Session(self._target, graph=self._graph, config=config)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/client/session.py", line 1596, in __init__
    super(Session, self).__init__(target, graph, config=config)
  File "/home/jovyan/.local/lib/python3.7/site-packages/tensorflow/python/client/session.py", line 711, in __init__
    self._session = tf_session.TF_NewSessionRef(self._graph._c_graph, opts)
tensorflow.python.framework.errors_impl.InternalError: CUDA runtime implicit initialization on GPU:0 failed. Status: all CUDA-capable devices are busy or unavailable

I also verified if TF is able to see the GPUs using,

tf.config.list_physical_devices('GPU')

And it is able to see all the GPUs.

And I made sure there isn’t any process locking the GPU. Do I have to import ray and TF in a specific order or something?

#7

Can you try this workaround (by putting it into the setup of your Trainable)?

def setup():
   os.environ['TF_FORCE_GPU_ALLOW_GROWTH'] = "1"
#8

No luck! Same error :frowning:
As I’m able to train on GPUs outside of ray.tune, I think it is some setting on tune’s side. To iteratively explore and debug any other ideas, we can setup a live debug session. I’m free after 12pm PT rest of the week.
